K180-SA-High Precision Injection Molding Machine Wholesale

High Precision Injection Molding Machine

K180-SA

  • share
K180-SA


  • DESCRIPTION

    UNIT



    K110-SA




    INTERNATIONAL SIZE RATING





    350





    A

    B

    C

    INJECTON UNIT

    Screw diameter

    mm

    40

    45

    50

    Screw L:D ratio



    22.5

    20.0

    18.0

    Shot volume

    cm3

    283

    358

    442

    Shot weight(PS)

    g

    257

    326

    402

    oz

    9.1

    11.5

    14.2

    Injection pressure

    Bar

    2231

    1763

    1428

    Injection rate

    cm3/s

    126

    159

    196

    Plasticizing capacity

    g/s

    16

    22

    26

    Max.screw speed

    r/min

    190

    CLAMPING UNIT

    Clamping force

    kN

    1800

    Space between tie bars

    mm

    520x470

    Platens size

    mm

     740x690

    Opening stroke

    mm

    460

    Min.moW height

    mm

    200

    Max.mokl height

    mm

    550

    Distance between platens<daylight)

    mm

     1010

    Ejector stroke

    mm

    130

    Ejector force

    kN

     50

    Number of ejector



     5

     POWER UNIT

    Systefm pressure

    Bar

     175

    Pump motor

    kW

    22

    Heating capacity

    kW

     10.0

    GENERAL

    Oil tank capacity

    L

    170

    Machine dimension(LxWxH)

    m*m*m

      5.2x1.3x2.0

    Machine weight

    t

    6.0

    Hopper capacity

    kg

    50

High standard factory

about KSM Machinery

Ningbo KSM Machinery Manufacturing Co.,Ltd. is a cooperate with Italy technologies specialized high-grade plastic in production of high-grade plastic molding machine. Our corporation is located in Ningbo Beilun Xing Ao Industrial Park. We have a number of R&D personnel and cooperate with a group of high-tech enterprise.
As a professional China K180-SA-High Precision Injection Molding Machine suppliers and OEM/ODM K180-SA-High Precision Injection Molding Machine company, It mainly produces high precision injection molding machines with the clamping force range from 110T to 1850T. The products have high rigidity structure and equipped imported hydraulic & electrical elements, used screw with mixing head in order to have excellent plastifying performance and be suitable for various engineering plastic injection molding and the uers'special order are available.
Since its corperation established, has always paid attention to enterprise reputation,carrid out scientific, management with rational designs, rests with quality pre-sale, selling and after-sale services to win the vast number user's trust and approval.
We abide by the motto of "honest, keep on improving, lay stress on quality, never relax in effort". Sincerely welcome friends from all wask for guidance.
The company has a research and development center with strong development strength. At the same time, it cooperates with domestic universities and colleges to develop and research injection and plastic production equipment and injection molding machine. The company has advanced hose testing equipment and experimental equipment. In recent years, the R&D center has achieved many achievements in injection molding machine and plastic equipment, rubber vulcanization process and formulation development.
Sincerely invite customers at home and abroad to visit our factory, and look forward to your long-term corporation to create a beautiful tomorrow for you!

Why choose us

Our advantages

  • quality

    We have our own testing lab and advanced and complete inspection equipment, which can ensure the quality of the products produced by our equipment.

  • capacity

    Our annual production capacity is over 500 set injection molding machine.

  • service

    We focus on developing high-quality products for top-endmarkets. Our products are in linewith international standards, and are mainly exported to Europe, America,Japan and other destinations around the world.

  • shipment

    We are only 15 kilometers away from the Ningbo Port, it is very convenient and efficient to ship goods to any other countries.

Guarantee High Quality With Our Expertise

certifications

Our professional team can offer wireless full range service and customer-oriented service according to customers' individual requirements.
